51.2V 45Ah High-Capacity Battery for Heavy-Load Trikes
51.2V 45Ah ultra large capacity battery, stackable industrial grade battery pack, supports solar charging access, mainly used in logistics and freight electric tricycles, large electric tour buses in scenic spots, etc. Long service life, capable of meeting high-intensity usage needs for many years; Equipped with intelligent anti-theft function to ensure battery safety; Modular design for easy maintenance and replacement.
Specification
| Model | PRL-F48-45A |
|---|---|
| Material System | LiFePO4 15Ah Full-Tab Cell |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 45Ah |
| Cell Configuration | 16S3P |
| Charging Voltage | 57.6V |
| Max Charging Current | 20A |
| Max Continuous Discharge Current | 45A |
| Peak Discharge Current | 70A (5S) |
| Operating Voltage Range | 40V~57.6V |
| Charging Temperature | 0~55°C |
| Discharging Temperature | -20~65°C |
| Storage Temperature | -20~40°C |
| Dimensions | L220*W162*H325mm |
| Cycle Life | Cell: 2000 cycles (>80% capacity retention)Battery: 1200 cycles (>70% capacity retention) |
| Communication | Supports One-Link, RS-485, 4G, GPS, Bluetooth |
| Certifications | Customizable per client requirements |
Certification standards and testing
UN38.3, ISO 12405-2, and CE
accelerated life testing
Humidity test
Drop Test
Salt spray corrosion test
Thermal runaway
Cell balancing tests
Application
Passenger transport tricycles
Industrial hauling trikes
City cargo tricycles
